GANGSAW (MARBLE AND GRANITE) PENDULAM-80

This machine is designed and constructed ideally for cutting Marble & Granite blocks in slabs with high efficiency, Trouble free working with high speed, keeping in view all the safety measures and this all of course with very competitive cost.

• Drive System : This machine is consists of a heavy and well balanced fly wheel suitable for Reciprocate movement of saw frame. The drive on fly is obtained by an induction motor through flat belts. The shaft of the fly wheel is made by special steel, mounted on heavy C. I. Pedestals with large self Aligning Roller bearings.

• Saw Frame : Blade frame assembly is designed to with stand tension load, all stresses and vibrations during operation. Four special sliding guide units are provided to support & guide the reciprocating movement of the blade holder frame. These sliding guide units having self aligning system remain in Constant oil bath ensures remarkable precision during alternative motion of blades during the operation.

• Columns : Four heavy Columns of stiffened and shape steel are provided which are designed to with stand all movement of the frame during the operation.

• Trolley : The trolley performs up & down motion with the Marble & Granite block for cutting operation, on a Heavy duty platforms, which is guided by vertical tracks mounted on four columns.

TECHNICAL SPECIFICATION
Type of Machine PENDULAM
Size of block (Max.) 3000 X 1800 X 1800 MM
Length of Blades 4200 MM.
No. of Blades 80 Nos. Blades/ 20 MM.
Stroke length 650-750 MM.
No. of stroke 100/ 110 per min.
Sawing feed 50 to 400 MM/hr.
Blade tensioning Mechanical
Fast up & down motor 10 HP. Motor
Main Drive 150 HP./ 1440 with fluid coupling
Trolley loading 2 No. , Size 3200X1850mm. motorized
Overall dimension of Machine length-11500, width-5000, height-4500 MM
Total Weight of Machine 46000 Kg. Approx
